ArcFil Pro

Specifically suited for robot welding applications

Robust, reliable and solid - the central extraction system KemFil Pro Roboter for high levels of smoke and dust. Ideally suited for large welding shops, training centres or for connecting to cutting machines. The KemTex® ePTFE membrane filter cartridges for ultra-fine dust particles separate particles even below 0.1 µm. If your requirements change, the system can grow flexibly by means of modular extensions.

Product variants:

Price: Upon request
Art. No.
35 85
3585
Inquiry
Share this page
  • High levels of smoke and dust
  • Welding and grinding shops
  • Training centres and robotic welding lines
  • Laser, plasma and flame cutting systems
  • Can be installed outdoors
  • Contamination-free dust collection due to compressed air fixation of dust collection containers
  • Uninterrupted continuous operation due to automatic differential pressure-controlled filter cleaning
  • Little noise emission due to a low noise level
  • Considerable energy cost savings by using the automatic extraction volume control
  • Convenient operation due to intelligent control via touch screen with diagnostic system
  • Best health protection for employees by use of KemTex® ePTFE cartridges with surface filtration
  • Recirculation is possible even when using chrome-nickel steel thanks to W3 certification
  • Control via touch screen
  • KemTex® ePTFE filter cartridges
  • Automatic extraction volume control (optional)
  • Automatic filter cleaning on required basis
  • Control via compact touch information display
  • Low noise emissions thanks to extremely low noise level
  • Dosing unit for pre-coating the filter cartridges
  • Automatic dust disposal - DustEvac
  • Automatic extraction volume control
  • Fleet management, remote maintenance and pre-noise maintenance using autarkic networking via mobile radio to the KEMPER cloud
  • Spark separator – SparkTrap
  • Automatic start-stop
  • Weatherproof housing for outdoor installation
  • Various voltages
  • Various filter surfaces
  • Various volume flow rate capacities
Technical Data

Filter

Filter stages

1

Filter method

Cleanable filter

Filter cleaning method

Rotating nozzle

Filter surface

10 m²

Number filter elements

12

Filter surface total

120 m²

Type of filter

Filter cartridge

Filter material

ePTFE membrane

Filter efficiency

> 99.99 %

Dust classification

M

Basic data

Extraction capacity min.

6000 m³/h

Extraction capacity (max.)

8640 m³/h

Extraction capacity

6000 - 8640 m³/h

Air flow rate (max.)

12000 m³/h

Vacuum min.

2400 Pa

Vacuum

2400 - 1950 Pa

Working pressure in PA

1950 Pa

Dimensions (w x t x h)

2378 x 1864 x 2110 mm

Weight

1220 kg

Motor power

7.5 kW

Power supply

3 x 400 V / 50 Hz

Rated current

13.8 A

Noise level

65 dB(A)

Additional information

IFA-Certification

W3-Approved

Fan type

Radial fan, belt driven

Compressed air supply

5 - 6 bar

Air outlet

560 mm

Air intake

560 mm

Capacity Dust collection container

192 l

Dimensions

I

1382 mm

J

325 mm

K

560 mm

L

1364 mm

N

481 mm

O

1347 mm

*All prices are excluding VAT and carriage costs. Our offered products are directed exclusively to commercial businesses.
